Functionality you need for presentations and digital signage
Enhance your meeting and conferencing performance with stunning UHD resolution. Get high-end quality and reliability at a low total cost of ownership with long life-times.
Professional haze levels ensure great visibility without distracting reflections - along with brightness of up to 350 cd/m², the NEC E758 meets the demands of today’s meeting environments
An integrated MediaPlayer supports native UHD resolution and High Dynamic Range (HDR) for deep contrasts and natural looking content playback with auto-play function. Requiring no additional cables, external devices or signage software, the USB MediaPlayer enables a simple seamless professional signage solution.
With this NEC display presenters will feel confident during meetings of up to 12 participants whilst retailers and hospitality facilities can boost sales through digital signage. For instant start-up in meeting spaces, inputs are detected automatically with easy switching between HDMI sources. Facilities managers will welcome the ability to remotely control their digital estate via the network thanks to the integrated LAN and NEC’s NaviSet Administrator 2 functionality making this display the perfect choice for corporate meeting rooms and entry level digital signage.
Benefits
- Reduced Installation and Operating Costs – highly energy efficient LED backlit display ensures low power consumption, longer backlight lifetime and lighter design for easy transportation, mounting and integration.
- Slim Design and Integrated Speakers – the aesthetic design is pleasing to the eye and enables easy, low cost installation.
- Future Ready Connectivity – featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
- Standalone operation – the display is designed for straightforward standalone operation due to integrated USB media player, speakers and scheduling functionality.
- Effortless content playback – the integrated USB media player supports various image video file formats for effortless and standalone content playback.
Product Specifications
| Display | |
| Panel Technology | IPS |
| Screen Size [inch] | 98 |
| Aspect Ratio | 16:9 |
| Brightness [cd/m²] | 350 |
| Contrast Ratio (typ.) | 8000:1 |
| Viewing Angle [°] | 178 |
| Colour Depth [bn] | 1.073 (8bit + FRC) |
| Haze Level [%] | 28 |
| Supported Orientation | Landscape Portrait |
| Synchronisation Rate | |
| Horizontal Frequency [kHz] | 15 - 136 |
| Vertical Frequency [Hz] | 24 - 75 |
| Resolution | |
| Native Resolution | 3840x2160 |
| Supported Resolution | 1920x1080 3840x2160 1920x1200 4096x2160 640x480 1280x720 |
| Connectivity | |
| Input Video Analogue | 1 x VGA |
| Input Video Digital | 3 x HDMI |
| Input Audio Analogue | 1 x 3.5 mm jack |
| Input Audio Digital | 3 x HDMI |
| Input Control | LAN 100Mbit RS232 |
| Input Data | 1 x USB 2.0 (Media Player) 1 x USB Type-C (5V/3A, power for external devices) |
| Output Audio Analogue | 1 x 3.5mm jack |
| Output Audio Digital | 1 x SPDIF |
| Remote Control | Remote Control IR; RS-232C (9-pin D-sub) Input |
| Sensors | |
| Ambient Light Sensor | Integrated triggered actions programmable |
| Electrical | |
| Power Consumption [W] | 200-300 |
| Power Savings Mode [W] | < 0.5 < 2 (Networked Standby) |
| Power Supply | 100-240 V AC 50/60 Hz Internal |
| Environmental Conditions | |
| Operating Temperature [°C] | +0 to +40 |
| Operating Humidity [%] | 20 to 80 |
| Storage Humidity [%] | 10 to 90 |
| Storage Temperature [°C] | -20 to 60 |
| Mechanical | |
| Dimensions (W) [mm] | 2194.7 |
| Dimensions (H) [mm] | 1250.2 |
| Dimensions (D) [mm] | 84.3 |
| Exact Weight [kg] | 65.4 |
| Bezel Width [mm] | 15.9 (left and right); 15.9 (top and bottom) |
| VESA Mounting [mm] | 4 holes M8 |
| Material | Metal |
| Media Player | |
| Supported File Storage / File System | USB 2.0 / FAT16 FAT32 |
| Supported Image Formats | JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640 |
| Supported Video Formats | MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); audio: LPCM, MP3, AAC; WMV (video H.264, Windows Media Video 9, max res 1080p@30Hz, audio WMA 9, WMA 10 Pro) |
| Supported Audio Formats | MP3 (MP3); max. bit-rate 320 kBit/s |
| Green Features | |
| Energy Efficiency | LED backlight |
| Ecological Standards | EnergyStar 8.0 |
| Additional Features | |
| Special Characteristics | Ambient Light Sensor; Audio settings with equalizer; CEC Support; Colour temperature mode; Display Browser Control; Energy saving picture mode; HDMI with UHD at 60 Hz; HDR Gamma Support (HLG, PQ); Mac and Windows compatible; NaViSet Administrator 2; Powered USB-Port; Retail picture mode; Scheduler; SNMP Support; USB Media Player |
| Safety and Ergonomics | Energy Star 8.0 RCM EMC Class B PSB UL/C-UL VCCI |
| Audio | Integrated Speakers (10W + 10W) |
| Shipping Content | Display HDMI Cable Power Cable Remote Control 2x AAA Batteries Setup Manual |
| Warranty | 3 years warranty incl. backlight |
| Operating Hours | 24/7 |
| External Control | Crestron Connected |
